Pixelhue U5 Pro
-
Contact us for a quote
Pixelhue U5 Pro flagship event controller with 43.8" touchscreen, built-in PixelFlow and timecode/MIDI. Request a quote, shipped from Sweden by UPS Express.
Fast delivery from Sweden
Shipped next business day
No Import Duties
Very few exceptions
High quality with EU warranty
For the best price on the market
Fast Support
Article Number:
N-78-510-10
Supplier:
Pixelhue
The Pixelhue U5 Pro is Pixelhue's flagship event controller for large-scale live events, concerts, broadcast and corporate shows. It controls several Pixelhue presentation switchers and media servers at the same time from one console, with PixelFlow software built in.
Built on an NVMe SSD-based core architecture, the U5 Pro is made for fast, fluid operation under pressure. A 43.8" ultrawide main touchscreen, an 8" smart touchscreen, 203 programmable LCD buttons and a high-resolution T-bar give the operator everything on one surface.
Key Features
- Built-in PixelFlow software with a new, easier GUI
- Controls multiple presentation switchers and media servers simultaneously, such as the Q8
- Timecode generation, reception and conversion: LTC, MTC and MIDI over USB
- Controls third-party devices via MIDI
- KVM and PTZ camera control
- 43.8" ultrawide main touchscreen + 8" smart touchscreen
- 203 user-programmable LCD buttons with replaceable skins and styles
- 4 encoders and 8 faders, configurable as software function buttons or MIDI controls
- High-resolution T-bar
- Built-in keyboard and two extra drawers
- Anti-corrosion aluminium housing, designed for easy disassembly and maintenance
U5 Pro, U5 or U5 Mini?
- U5 Pro: the flagship console for mega events, with the largest screens, timecode and MIDI.
- U5: full-size event controller for most touring and rental setups.
- U5 Mini: compact, USB-C powered controller in T-Bar or Fader versions.
Specifications
| Main screen | 43.8" ultrawide touchscreen |
| Second screen | 8" smart touchscreen |
| Controls | 203 LCD buttons, 4 encoders, 8 faders, T-bar, built-in keyboard |
| Timecode | LTC, MTC, MIDI USB |
| Power | AC 100–240 V, 50/60 Hz, max 330 W |
| Noise | 40 dB average |
| Operating temperature | 0 °C to 45 °C |
| Dimensions | 1129.6 × 695.4 × 422.7 mm (with handles, rack ears and rack mount) |
| Weight | 46 kg net, 107 kg with accessories and flight case |
Request a Quote
The U5 Pro is sold on quote. Contact Pixel Pitchers for price and delivery time. We ship from Sweden by UPS Express, with no EU import duties. See all Pixelhue products.
