MiracleWall COB FHD P0.9 - Bundle

MiracleWall COB FHD P0.9 is the most compact Full HD solution in our MiracleWall range, designed for premium environments where viewers sit close to the screen and image sharpness is critical. Built with Flip-Chip COB technology, common cathode design, full grayscale calibration, and next-generation NovaStar drivers, it delivers deep blacks, excellent contrast, stable performance, and low power consumption.

This webshop package includes everything needed to install a complete Full HD LED wall — mounting, controller, trim, cables, and display modules.

For customers comparing variants, physical size is one of the most important differences. Because this is the finest pitch in the series, it also gives the smallest physical Full HD screen: 1800 × 1012.5 × 31 mm, with a diagonal size of 81.3" and a 3 × 3 cabinet layout. That makes it ideal where wall space is limited but near-viewing quality is essential.

Download Specification

• MiracleWall COB FHD Specification
• MiracleWall COB FHD P0.9 Information



Key features

• Flip-Chip COB (Full Flip-Chip)
• 1920 × 1080 Full HD resolution
• 600 nits brightness
• 3840 Hz refresh rate
• 1000000:1 contrast ratio
• 170° / 170° viewing angle
• 31 mm ultra-thin cabinet
• Full front service design
• NovaStar MX20 COEX processor included in package

Screen size

• Physical size: 1800 × 1012.5 × 31 mm
• Diagonal: 81.3"
• Display area: 1.82 m²
• Cabinets: 3 × 3 (9 pcs)



Complete package includes

• MiracleWall COB FHD LED panels
• Horizontal wall brackets
• Side trim
• NovaStar COEX MX20
• Power cables
• Signal cables



Other variants

Need a larger Full HD wall?

• MiracleWall COB FHD P1.25 – larger 108.4" format
  Product page: MiracleWall COB FHD P1.25 Product Page
  Download specification: MiracleWall COB FHD P1.25 Information
• MiracleWall COB FHD P1.56 – larger 135.5" format
  Product page: MiracleWall COB FHD P1.56 Product Page
  Download specification: MiracleWall COB FHD P1.56 Information
• MiracleWall COB FHD P1.87 – largest 162.6" format
  Product page: MiracleWall COB FHD P1.87 Product Page
  Download specification: MiracleWall COB FHD P1.87 Information
