NovaStar NovaPro UHD
- 0 EUR
NovaStar NovaPro UHD all-in-one controller, discontinued. Its successor, the NovaPro UHD Jr, is available from Pixel Pitchers and ships from Sweden.
This product is not available for order.
Fast delivery from Sweden
Shipped next business day
No Import Duties
Very few exceptions
High quality with EU warranty
For the best price on the market
Fast Support
Article Number:
148
Supplier:
NovaStar
NovaPro UHD is an advanced all-in-one controller crafted by NovaStar. This innovative device seamlessly combines video processing and control, boasting the integrated Master VI platform software for effortless screen configuration via mouse, keyboard, and monitor.
Capable of receiving diverse video signals, the NovaPro UHD processes resolutions up to Ultra HD 4K×2K@60Hz and 8K×1K@60Hz. With a maximum loading capacity of 10,400,000 pixels, it efficiently transmits processed videos to LED displays through Neutrik Ethernet ports and fiber optical ports. Widely utilized in high-end rentals, stage control systems, and fine-pitch fixed LED displays, the NovaPro UHD stands out for its powerful video processing and sending capabilities.
Key Features
- Industry-Standard Inputs: 4x 12G-SDI (IN-LOOP), 1x HDMI 2.0 (IN-LOOP), 1x DP 1.2, and 4x HDMI 1.3. (DVI input card available for connector replacement.)
- Neutrik Ethernet Outputs and OPT Outputs: 16x Neutrik Ethernet outputs and 4x OPT outputs with copy and hot backup modes.
- Layer Management: 6x layers, flexible adjustment options, irregular layer support, and Z-order sorting.
- OSD, LOGO, and BKG: OSD with cropping, opacity adjustment, dynamic/static images, and position settings; LOGO with resolutions up to 256×256, cropping, opacity adjustment, and position settings; auto-scaled BKG.
- Built-in Master VI Platform: Streamlined operations for easier control.
- HDR Function Support: Works seamlessly with A8s or A10s Plus receiving cards for enhanced image quality.
- Low Latency Output: Achieve as low as 1-frame end-to-end delay with low latency and synchronization functions enabled.
- Multiviewer Settings: Monitor input sources, PVW or PGM, or perform mixed monitoring.
- Web Control: Real-time access and control via a browser without additional software installation.
- Linkable Units: Connect up to four NovaPro UHD units for impressive image mosaics.
- Decimal Frame Rates: Supports frame rates of 23.98 Hz, 29.97 Hz, 47.95 Hz, 59.94 Hz, 71.93 Hz, 119.88 Hz, and 143.86 Hz.
- Genlock Synchronization: Ideal for XR application scenarios.
- PGM Editing: Full PGM editing support.
